Proface Proface PFXZCBCBCVR41 Price

The Video-Mix module (262000 color video input, 4 channel x, DVI input DVI output x 1 channel, 1 channel x, VGA/SVGA/XGA) *110.4 inches (TFT), the replacement of the host backlight (1).When the man-machine interface is installed to the hard panel to provide dust and moisture proof function (1)Screen size: 12.1 inches.
Display type: TFT color LCD.
Display color: 256 color (no flash) /64 color (3 speed flicker) PFXZCBCBCVR41
Backlight: CCFL (service life: more than 50000 hours, 24 hours of continuous work).
Resolution: 800 x 600 pixels.
Brightness control: 4 level adjustment can be carried out by touch panel.
Voltage: AC220V.
Internal memory: FLASH EPROM 4MB.
Backup memory: 256KB SRAM.
Interface: Ethernet, CF card. 12.1 inches /10.4 inches (STN), the GP installed to the hard panel to provide dust and moisture proof function.Display type: TFT color LCD.
Screen size: 10.1 inch widescreen.
Resolution: 800 x 480 pixels (WVGA).
Effective display area: H131.76mm * W219.6mm.
Display color: 65536 color.
Backlight: LED.
Brightness adjustment: 8 level adjustment can be carried out by touch panel.
Backlight lamp life: 20000 hours or more (in a 25 C environment, continuous work - brightness decreased to 50% of the original).
Language: Chinese (simplified).
Character size: 8 x 8 pixels, 8 x 16 pixels, 16 x 16 pixels and 32 x 32 pixels.
Font size: 2, 4,, 8, 1,, 2,,, 1, 8, and 4 times.
Interface: x1 RS-232C, x1 RS-422/485, Type-A x1 USB, Mini-B x1 USB (for the project file upload / download).
Input voltage: DC24V.
Using 65536 color 3D simulation components, you can create a beautiful appearance of the operation of the screen.
Due to the use of a widescreen display, so in a picture can also place a keyboard.
Variety of switches and lights and other basic functions can be used in 65536 colors.Used to connect the 2-Port adapter to GP4000Controller DIO (PNP model):6 point type NPN input, 2 point NPN type output, connector: 12 pin.
Specification: DC24/C (control) level models.
Display type: TFT color LCD (Gao Liangdu).
Display size: 12.1 inches.
Resolution: 800 x 600 pixels (SVGA).
Display color: 65536 color (no flash) /16384 color (3 speed flicker).
Brightness adjustment: 8 level adjustment can be carried out by touch panel.
Variable area: 64KB SRAM (using lithium battery).
Program area: EPROM 132KB FLASH.
Step number: equivalent to 15000 steps.
Touch panel type: resistance type (analog).
Can improve the efficiency of the 5 functions.
Using EX GP-Pro can easily create a clear picture and save the creation time.
Screen and logic programming software EX GP-Pro interface is very friendly,
The drag and drop feature makes the software interface easy to operate.
EX GP-Pro powerful features, such as 3D simulation components, image fonts and simulation functions,
Even beginners can easily and quickly grasp how to create a picture.
Simulated running status on PC.
Use PC simulation function, do not need to transfer the picture to GP,
You can check all the functions of GP on the PC - including the screen operation, D script, logical script.
Rich sample images can reduce programming time.
Pro-face provides a large number of sample images and 3D parts,
So you can easily create a beautiful and intuitive picture, in order to save editing time.
PFXZCBCBCVR41 Operation manual / Instructions / Catalog download link: /searchDownload.html?Search=PFXZCBCBCVR41&select=5
